- FEATURES
• It is mainly used for quilting quilts, mattresses, bedspreads and other bedding.
• The machine structure has been optimized, and the steel thickness has been increased. The machine head adopts the optical axis track, and the quilting speed can reach 2800- 3001) грт.
• All patterns are stored on the hard disk, and new patterns in DST format can be loaded and uploaded with a USB flash disk at will, which is convenient and flexible.
• The computer can be switched between Chinese, English and Russian freely. The user can select the working parameters to be used, such as step length and needle speed, according to the screen prompts.
- Main Technical Parameters – SS-B-C-3032
| Parameter | Specification |
|---|---|
| Type | SS-B-C-3032 |
| Quilting Size | 3.0 × 3.2 m |
| Needle Drop Size | 2.8 × 3.0 m |
| Sewing Machine Type | Single-line style, Double-line lock stitch, Big Rotary Shuttle |
| Maximum Sewing Thickness | 1200 g/m² |
| Sewing Speed | 3500 SPM (Stitches Per Minute), Stitch Length: 2–7 mm |
| Needle Type | SINGER MR5, Size 18–22# |
| Power Supply | 220V AC, 50 Hz, 1.5 kW |
| Machine Dimensions | 5.2 × 4.2 × 1.75 m |
| Weight | 1800 kg |
