✔️ Advanced screw extrusion design for stable and uniform foaming.
✔️ High production capacity with multiple model options.
✔️ Fully automatic operation with user-friendly control system.
✔️ Adjustable thickness from 0.35mm to 30mm.
✔️ High foaming ratio (up to 48x).
✔️ Widely used in electronics, household items, and industrial packaging.
| ✅ Model | ✅ Screw Dia. (mm) | ✅ Screw L/D | ✅ Prod. Capacity (kg/h) | ✅ Sheet Thickness (mm) | ✅ Foaming Ratio | ✅ Total Power (kW) | ✅ Dimensions (L×W×H, mm) | ✅ Weight (Tons) |
|---|---|---|---|---|---|---|---|---|
| SS-75 | 75/90 | 55:1 | ≤100 | 0.35–5 | 15–48 | 75/90 | 22000×1700×2200 | 4/5 |
| SS-90 | 90/120 | 55:1 | ≤180 | 0.35–5 | 15–48 | 90/120 | 21000×1500×2200 | 8.5 |
| SS-105 | 105/130 | 55:1 | ≤220 | 0.35–5 | 15–48 | 110/130 | 22000×1500×2200 | 10 |
| SS-120 | 120/150 | 55:1 | ≤300 | 0.35–5 | 15–48 | 130/150 | 22000×1500×2200 | 12 |
| SS-135 | 135/160 | 55:1 | ≤350 | 0.35–5 | 15–48 | 160/180 | 24000×1600×2300 | 16 |
| SS-150 | 150/170 | 55:1 | ≤400 | 0.35–5 | 15–48 | 200/220 | 26000×1800×2300 | 18 |
| SS-160 | 160/180 | 55:1 | ≤500 | 0.35–5 | 15–48 | 220/240 | 27000×1800×2300 | 20 |
| SS-80 | 180/200 | 55:1 | ≤600 | 0.35–5 | 15–48 | 260/280 | 28000×1800×2300 | 24 |
| SS-200 | 200/220 | 55:1 | ≤700 | 0.35–5 | 15–48 | 300/320 | 29000×1800×2300 | 26 |
| SS-220 | 220/250 | 55:1 | ≤800 | 0.35–5 | 15–48 | 350/380 | 30000×1800×2300 | 28 |
